Monel woven wire mesh
Monel Woven Wire Mesh
Monel 400 and K500 woven wire mesh with outstanding corrosion resistance in seawater and chemical environments.
Specifications
- Materials
- Monel 400, Monel K500
- Mesh range
- 8-200 mesh
- Weaves
- Plain, twill
- Wire diameter
- 0.0021-0.028 inch
- Uses
- Marine piping, petrochemical, heat exchangers
Construction and specifications
Monel mesh is manufactured from nickel-based alloy; Alloy 400 offers outstanding corrosion resistance in flowing seawater, Alloy K500 adds aluminum for greater tensile strength.
Where it is used
Marine piping and strainer baskets, petrochemical processing equipment and heat exchangers, resistant to seawater, chemical solvents and alkaline media.
Ordering guidance
Specify mesh count, wire diameter and alloy (400 or K500).
