Woven Rod Bar Belt
Woven Rod Bar Conveyor Belt
Woven rod bar belt built from solid round weft wires and stranded multi-wire warp cables for through-air drying, dewatering and IQF freezing.
Specifications
- Construction
- Round weft rods + stranded warp cables
- Width
- Up to 3500 mm
- Weft wire diameter
- 1.5-2.5 mm
- Materials
- SS304, SS316, heat-resistant alloys
- Typical use
- Food drying, dewatering, IQF freezing
Woven Rod Bar Conveyor Belt
Product Description
Woven Rod Bar Conveyor Belt is a heavy-duty metal conveyor belt made from solid round weft wires and multi-wire warp cables. The transverse rods provide a stable carrying surface, while the longitudinal warp cables provide high tensile strength.
Its open mesh structure allows efficient airflow, heat transfer, and drainage, making it suitable for continuous drying, baking, dewatering, freezing, and industrial conveying applications.
Key Features & Benefits
- High Tensile Strength: Multi-wire warp cables provide excellent load-bearing capacity and durability.
- Open Mesh Structure: Allows efficient circulation of hot air, cold air, steam, and water.
- Stable Carrying Surface: Smooth round weft wires support products during conveying.
- Flexible & Durable: Designed for continuous operation and repeated bending.
- Corrosion Resistance: Stainless steel construction is suitable for food processing and demanding environments.
- Customizable Design: Belt width, wire diameter, warp cable pitch, and edge type can be customized.
- Easy to Clean: Open stainless steel mesh supports convenient cleaning and sanitation.
Edge Options
Cut Edge: A cost-effective standard option for general conveyor applications.
Welded Edge: Reinforced edge design that helps prevent wire migration and fraying during heavy-load or high-speed operation.
Standard Specifications
Item | Available Options |
|---|---|
Belt Width | Up to 3,500 mm, customized |
Warp Wires | 1, 2, 3, or 4 wire ropes |
Weft Wire Diameter | 1.5–2.5 mm |
Warp Cable Pitch | 8.0–24.0 mm |
Edge Type | Cut edge / Welded edge |
Material | SS304 / SS316 |
Joining Method | Pin joint / Endless seam / Fastener clip |
Applications
Food Processing
- Vegetable, fruit, and mushroom drying
- Pasta and noodle drying
- Bread, biscuit, and snack baking
- Fish and seafood IQF freezing
- Food dewatering and washing
Agricultural Processing
- Grain drying
- Tobacco leaf drying
- Hops and green fodder drying
- Bulk agricultural product processing
Industrial Applications
- Chemical and pellet drying
- High-temperature conveying
- Industrial dryers
- Thermal processing equipment
- Corrosion-resistant conveying systems
